Transmission: Manual, 10 forwards and 2 reverses Cabin: 3 persons with AC Engine capacity: 300HP Curb weight: 9850kg Axle load: 7000/16000kg Max Driving speed: 90Km/h Clutch: Reinforce diaphragm. Brakes: Air Brakes Steering gear: Power Assist 4 stroke injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling, mechanical high pressure oil pump system Maximum output: 290PS (247kW) at 2200 rpm Maximum torque: 1350Nm at 1100-1600rpm Bore: 126mm Stroke: 130mm Displacement: 9.726L Compression ratio: 17.5:1 Specific fuel consumption: ?198g/kWh Engine oil filling quantity: 23L Air compressors: WABCO Twin cylinders air compressors; Cooling system filling quantity(long-term filling): 40L CLUTCH: SINOTRUK’s 430C diaphragm spring clutch, hydraulically operating with air assistance PROPELLER SHAFT: Double universal joint propeller shaft with gear-shaped coupling flange STEERING: hydraulic steering with power assistance BRAKE SYSTEM: Front and rear drum brake, four-circuit protection valve Service brake: dual circuit compressed air brake Parking Brake: spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake DRIVER'S CABIN: Long cab, all steel forward control, 55° hydraulic tilting to the front, 2-arm windscreen wiper system with 3 speeds,VDO electrical control system, laminate windscreen, with casted-in radio aerial, adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, with stereo radio/cassette recorder, one sleeper,sun visor, safety belt, air conditioner, adjustable steering wheel. ELECTRICAL SYSTEM: Operating voltage:24V, negative grounded Starter: 24V, 7.5KW Alternator: 3-phrase, 28V, 1540W Batteries: 2×12V, 165Ah Cigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp WEIGHT: Permissible loading capacity (kg) 16000 Dead weight (kg) 10500 Gross vehicle weight (kg) 16000 Gross combination weight (kg) 16000 Front axle loading capacity (kg) 9000 Rear axle loading capacity (kg) 16000 PERFORMANCE: Maximum driving speed(km/h) 78(reference data) Maximum gradeability (%) 36 Minimum ground clearance(mm) 314 Minimum turning radius (m) 15 Fuel consumption(L/100km) 40(reference data)
